ACA826T High-Precision CAN Inclinometer with Full Temp Compensation for Leveling

Name: ACA826T HighPrecision CAN Inclinometer with Full Temp Compensation for Leveling
Brand: RION
Price: 680.00 USD

Buy cheap ACA826T High-Precision CAN Inclinometer with Full Temp Compensation for Leveling product

Brand Name : RION

Model Number : ACA826T-C2

Certification : CE, ISO

Place of Origin : Guangdong, China

MOQ : 1

Price : $680.00/Pieces >=1 Pieces

Payment Terms : T/T,Paypal

Supply Ability : 1000 Piece/Pieces per Month

Delivery Time : 7 days for samples

Packaging Details : Carton

Measure range : ±3/10/15/30°

Measure axis : X/XY

Resolution : 0.0005°

Measure accuracy : 0.002/0.03/0.05/0.01°

Response time : 20Hz

Weight : 152g

Working Temp.(℃) : -40~+85℃

Input Voltage : 9~36VDC

Contact Now

ACA826T High-Precision CAN Inclinometer with Full Temp Compensation for Leveling

The ACA816T/ACA826T is a high-precision single/dual-axis inclinometer developed by RION Technology, featuring CAN 2.0A/B output and full temperature compensation. Designed specifically for high-accuracy leveling applications, it offers an exceptional resolution of 0.0005°, making it a reliable digital alternative to traditional spirit levels.

The sensor supports digital signal transmission and can work seamlessly with PC software for simultaneous angle measurement and data recording. Its non-contact installation design ensures high compatibility—simply mount the sensor onto the target surface using screws, and it will automatically calculate the inclination.

With robust resistance to electromagnetic interference, as well as shock and vibration, the ACA816T/ACA826T delivers stable performance in harsh environments and offers a distinct competitive edge in the high-precision sensor market.

▶ SPECIFICATIONS

ACA816T/826T-C2	Condition	Parameter				Unit
Measure range		±3	±10	±15	±30	°
Measure axis		X/XY	X/XY	X/XY	X/XY
Resolution		0.0005	0.0005	0.0005	0.0005	°
Measure accuracy	@25℃	0.002	0.003	0.005	0.01	°(RMS)
Long term stability		0.01	0.01	0.02	0.02	°
Zero temp. coefficient	-40~85℃	±0.0002	±0.0002	±0.0002	±0.0002	°/℃
Sensitivity temp. coefficient	-40~85℃	≤50	≤50	≤50	≤50	ppm/℃
Power on time		0.5	0.5	0.5	0.5	S
Response time		20	20	20	20	Hz
Output rate	20Hz, can set
Output signal	CAN 2.0A/CAN2.0B (optional)
EMC	According to EN61000 and GBT17626
MTBF	≥98000 hours/times
Insulation Resistance	≥100MΩ
Shockproof	100g@11ms / 3 axis direction (half sinusoid)
Anti-vibration	10grms / 10~1000Hz
Protection grade	IP67
Cables	With 2 meter, wear-resistant, wide temperature, shielded cable 5P*5.7mm aviation connector
Weight	235g( exclude cable)

▶ ELECTRICAL PARAMETERS

PARAMETERS	CONDITIONS	MIN	STANDARD		MAX	UNIT
Power supply	Standard	9	12	24	36	V
Power supply	customized		Other voltage			V
Working current	12V		40			mA
Working current	24V		22			mA
Working temperature		-40			+85	℃
Store temperature		-40			+85	℃
