Brand Name : Rion
Model Number : HCA716S / HCA726S
Certification : CE, ISO
Place of Origin : Guangdong, China
MOQ : 1
Price : $280.00/Pieces >=1 Pieces
Payment Terms : T/T,Paypal
Supply Ability : 3000 Piece/Pieces per Month
Delivery Time : 7 days for samples
Packaging Details : 1pcs/box with sponge inside, 100pcs/ctn
Measure range : ±10~±180°
Long temp. stability : <0.02°
Resolution : 0.001°
Power on time : 0.5S
Interface : CAN2.0A/CAN2.0B
EMC : According to EN61000 and GBT17626
MTBF : ≥98000 Hours/times
Insulation Resistance : ≥100M
HCA716S / HCA726S A SMALL VOLUME HIGH-PRECISION INCLINOMETER CAN2.0A/B OUTPUT
▶ KEY FEATURES
★ Single/dual Axis Inclinometer
★ Measuring Range :±1~±180° optional
★ Accuracy: refer to the technical data
★ Wide voltage input: DC9~36V
★ Wide temperature working: -40~+85℃
★ Resolution: 0.001°
★ IP67 protection class
★ Highly anti-vibration performance >100g
★ Direct lead cable interface
★ Small size : 54×46×20.5mm(customized)
▶ APPLICATION
★ Monitoring of ancient buildings and dilapidated buildings
★ Monitoring of bridges and large lands
★ Leveling of construction vehicles
★ Mining machinery, oil drilling equipment
★ Medical equipment angle control
★ Railway gauge ruler and gauge leveling
★ Underground drilling rig attitude navigation
▶ SPECIFICATIONS
| CONDITION | PARAMETER | UNIT | |||||
Measure range |
| ±10 | ±30 | ±60 | ±90 | ±180 | ° | |
Measure axis |
| X Y | X Y | X Y | X Y | Vertical X axis | axis | |
Resolution |
| 0.001 | 0.001 | 0.001 | 0.001 | 0.001 | ° | |
Measure accuracy | MAXE | Room temp. | 0.008 | 0.01 | 0.01 | 0.02 | 0.02 | ° |
RMSE | Room temp. | 0.004 | 0.005 | 0.005 | 0.006 | 0.006 | ° | |
Long temp. stability |
| <0.02 | <0.02 | <0.02 | <0.02 | <0.02 | ° | |
Zero Temp.coefficient | -40~85℃ | ±0.0005 | ±0.0005 | ±0.0005 | ±0.0005 | ±0.0005 | °/℃ | |
Sensitivity temp-coeffi | -40~85℃ | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | ≤0.01 | %/℃ | |
Power on time |
| 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | S | |
Response frequency |
| 20 | 20 | 20 | 20 | 20 | Hz | |
Interface | CAN2.0A/CAN2.0B | |||||||
EMC | According to EN61000 and GBT17626 | |||||||
MTBF | ≥98000 Hours/times | |||||||
Insulation Resistance | ≥100M | |||||||
Shockproof | 100g@11ms,3 Axial Direction (Half Sinusoid) | |||||||
Anti-vibration | 10grms,10~1000Hz | |||||||
Protection grade | IP67 | |||||||
Cables | Standard 1M length,wearproof,grease proofing,wide temperature, Shielded cables 4*0.2mm2 | |||||||
Weight | ≤150g (including 1 meter cable) |
![]() |
